Name: kitchen countertops pad (Pad strip)
Application: Used for kitchen countertops pad, pad strip.

Usage: Artificial stone countertops pad, generally used 12mm honeycomb panels with non-woven fabric, the thickness of 25 mm. Usage One: Before the countertops go out the plant, paste fireproofing board or plastic plate under the honeycomb panels, and then paste the honeycomb panels under the countertops, which can also be pasted on the construction site. Usage Two: Use pad strip with the width of 60mm, plywood and fireproofing board can be applied on the upper and lower surface.

Features:  Anti-crack, leveling, waterproof, non-deformation.

Technical indicators:


  Material

  Transparent PVC sheet

  Specifications

  Margins (Aperture) S=12mm   S=8mm

  Size

  Width: 520--610mm; Length: 2400mm, according to user requirements.

  Honeycomb height

  20---120mm(according to user requirements)  commonly use thickness of 25mm, 30mm

  Bulk density

  50kg/m3

  Compressive strength

  0.7-1.0Mpa

  Operating temperature

  PVC: --40℃ -- +50℃

   Honeycomb surface

  non-woven fabrics
